    HGO High Pressure Airline Filters

    hgo-high-pressure-airline-filters

     Advantages

    • Durable and compact

    • Safe and efficient operation

    • High performance

    • Strong and reliable design

    • Excellent high-pressure applications

    • Product performance warranty

    • Carbon steel filters designed for 350 bar (optional)

    • Sufficient wall thickness

    • High-pressure tested

    • Anodised interior and exterior surfaces

    This model filters are produced in a weldless structure to withstand high pressures.

    High-pressure test guarantee safe and efficient operation.

    TECHNICAL  SPECIFICATIONS


    Model Max.
    Pressure    		 Capacity Connection
    Size    		 Element
    Model    		 Dimensions (mm)
    bar psi m³/min cfm A B C D
    HGO 100 50 725 1,70 59 G ¼” M25 113,4 115,4 25,75 155
    HGO 300 50 725 5,00 177 G ½” M50 113,4 115,4 25,75 158,5
    HGO 600 50 725 10,00 353 G ¾” M100 109,4 115,4 32,25 207
    HGO 850 50 725 14,20 500 G 1” M150 133 138 37,35 250
    HGO 1200 50 725 20,00 706 G 1” M200 133 138 37,35 314
    HGO 1600 50 725 26,70 942 G 1 ½” M250 128 138 44,4 368
    HGO 2500 50 725 41,70 1471 G 2” M2500 145 158 51,5 393
    HGO 3000 50 725 50,00 1766 G 2 ½” M3000 160 178 57,6 386
